DMX Controller Artnet Node 4*512 Channel

Basic Info

Model NO.	lightning 4
Specification	125x70x45MM
Trademark	ibestwork
Origin	China
HS Code	9405409000
Production Capacity	2000PCS/Month

Product Description

Lightning is an easy-to-use and reliable Art-Net node. Because of this, you can use the device with applications, consoles, desks, or controllers that are compatible with Art-Net to distribute Art-Net data via Ethernet network.
With the default profile, each DMX Port is mapped to it's respective Art-Net Universe, allowing you to directly plug-in Lightning without any changes or configuration necessary.

Product Name	Lightning 1	Lightning 4		Lightning 12	Lightning 20	Lightning 30
Windows XP/Vista/7/8	√	√		√	√	√
Universe Setting	√	√		√	√	√
Universe	1	4		12	20	30
CPU	ARM	ARM	ARM+FPGA
Support Software	Madrix,Resolume,Arkaos ,etc
Input Protocols	Art-Net II ,Art-Net III
Configuration(Web Browser)	Ethernet IP Address ,Node Name
Output Protocol	DMX-512
Input Connection	RJ45
Output Connection	5Pin/3Pin XLR
Input Isolation	External Ethernet port Isolated to 2kV
Output Interface Protection	TVS,PTC, DMX Output Ground Referenced , +15kV ESD DMX Driver Protection
Mains Fuse			1A Slow Blow
Mains Earthing			Case connected to Mains Earth
Input Voltage	DC 5V-24V	DC 5V-24V	AC 90V-250V
Input Power (max)	2W	2W	5W
Certification	CE, FCC, RoHS
Overall Dimensions	71x63x38MM	125x70x45MM	1RU (H) x 19" Rack (W) x 120mm (D)		2RU (H) x 19" Rack (W) x 200mm (D)
